Cycle Sort is a comparison-based sorting algorithm that minimizes memory writes by placing each element directly into its correct position using cycles.

What is the time complexity of Cycle Sort?

Cycle Sort has a best-case, average, and worst-case time complexity of O(n²), although it performs the minimum possible number of memory writes.

Is Cycle Sort stable?

No. Cycle Sort is not a stable sorting algorithm because equal elements may change their relative order during placement.

Is Cycle Sort an in-place algorithm?

Yes. Cycle Sort is an in-place sorting algorithm that requires only O(1) additional memory.

Why should I learn Cycle Sort?

Cycle Sort is unique because it minimizes memory writes, making it valuable for understanding write-efficient algorithms and situations where writing to memory is expensive, such as flash storage or EEPROM devices.

Playground Component

Cycle Sort
Visualizer

An interactive Cycle Sort visualization built with HTML, CSS, and JavaScript. Watch how the algorithm minimizes memory writes by placing each element directly into its correct position, complete with adjustable animation speed.

Cycle Sort Visualizer

Copy Code



<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title> Sort Visualizer</title>

<!-- <link href="https://fonts.googleapis.com/css2?family=Poppins:wght@400;500;600;700&display=swap" rel="stylesheet"> -->

<style>
*{
    margin:0;
    padding:0;
    box-sizing:border-box;
}

:root{
    --bg:#090909;
    --panel:#111111;
    --panel2:#171717;
    --gold:#f4c430;
    --gold2:#ffd54d;
    --border:#3a2d08;
    --text:#f5f5f5;
}

body{
    font-family:'Poppins',sans-serif;
    background:
        radial-gradient(circle at top,#1b1606 0%,#090909 35%),
        var(--bg);
    color:var(--text);
    min-height:100vh;
    display:flex;
    flex-direction:column;
    align-items:center;
    padding:40px 25px;
}

h1{
    font-size:3rem;
    font-weight:700;
    color:var(--gold);
    margin-bottom:30px;
    text-shadow:0 0 18px rgba(244,196,48,.18);
    letter-spacing:.5px;
}

.controls{
    display:flex;
    gap:18px;
    flex-wrap:wrap;
    justify-content:center;
    margin-bottom:35px;
}

button{
    min-width:170px;
    padding:15px 22px;
    font-size:17px;
    font-weight:600;
    border-radius:14px;
    border:1px solid #705510;
    background:linear-gradient(180deg,#ffd54d,#e7b817);
    color:#121212;
    cursor:pointer;
    transition:.28s;
    box-shadow:
        0 8px 20px rgba(0,0,0,.45),
        inset 0 1px 0 rgba(255,255,255,.35);
}

button:hover{
    transform:translateY(-3px);
    box-shadow:
        0 14px 30px rgba(244,196,48,.22),
        inset 0 1px 0 rgba(255,255,255,.4);
}

button:active{
    transform:scale(.98);
}

#container{
    width:min(94%,1300px);
    height:590px;
    background:linear-gradient(180deg,#121212,#0b0b0b);
    border:1px solid var(--border);
    border-radius:24px;
    display:flex;
    align-items:flex-end;
    justify-content:center;
    gap:4px;
    padding:16px;
    box-shadow:
        0 20px 45px rgba(0,0,0,.55),
        inset 0 0 0 1px rgba(255,255,255,.03),
        0 0 35px rgba(244,196,48,.06);
    position:relative;
    overflow:hidden;
}

#container::before{
    content:"";
    position:absolute;
    inset:0;
    pointer-events:none;
    background:
        linear-gradient(rgba(255,255,255,.03) 1px,transparent 1px);
    background-size:100% 60px;
    opacity:.35;
}

.bar{
    width:12px;
    background:linear-gradient(to top,#b88700,#ffd54d);
    border-radius:4px 4px 0 0;
    transition:
        height linear,
        background .2s linear,
        transform .15s linear;
    box-shadow:0 0 10px rgba(244,196,48,.15);
    z-index:1;
}

@media(max-width:900px){
    h1{
        font-size:2.2rem;
    }

    button{
        min-width:145px;
        font-size:15px;
    }

    #container{
        height:470px;
    }

    .bar{
        width:8px;
        gap:2px;
    }
}
</style>
</head>

<body>

<h1>Cycle Sort  Visualizer</h1>

<div class="controls">
    <button onclick="randomize()">Randomize</button>
    <button onclick="cycleSort()">Sort</button>
    <button id="speedBtn" onclick="toggleSpeed()">Speed: Normal</button>
</div>

<div id="container"></div>

<script>

let sorting = false;

const speedLevels = [
    { name: "Very Slow", delay: 500 },
    { name: "Slow", delay: 120 },
    { name: "Normal", delay: 70 },
    { name: "Fast", delay: 35 },
    { name: "Very Fast", delay: 1 }
];

let speedIndex = 2;
let speed = speedLevels[speedIndex].delay;

const container = document.getElementById("container");

let values=[];

function toggleSpeed() {
    speedIndex++;
    if (speedIndex >= speedLevels.length) speedIndex = 0;
    speed = speedLevels[speedIndex].delay;
    document.getElementById("speedBtn").textContent =
        "Speed: " + speedLevels[speedIndex].name;
}

function createBars(){
    container.innerHTML="";
    values.forEach(v=>{
        const bar=document.createElement("div");
        bar.className="bar";
        bar.style.height=v+"px";
        container.appendChild(bar);
    });
}

function randomize(){
    values=[];
    for(let i=0;i<100;i++){
        values.push(Math.floor(Math.random()*350)+30);
    }
    createBars();
}

function sleep(ms){
    return new Promise(resolve=>setTimeout(resolve,ms));
}


async function cycleSort() {
    if (sorting) return;
    sorting = true;

    const bars = document.getElementsByClassName("bar");
    const n = values.length;

    for (let cycleStart = 0; cycleStart < n - 1; cycleStart++) {

        let item = values[cycleStart];
        let pos = cycleStart;

        // Find where to put the item
        for (let i = cycleStart + 1; i < n; i++) {

            bars[i].style.background = "#9c27b0";
            bars[cycleStart].style.background = "#ff3b30";
            await sleep(speed);

            if (values[i] < item) pos++;

            bars[i].style.background =
                "linear-gradient(to top,#b88700,#ffd54d)";
            bars[cycleStart].style.background =
                "linear-gradient(to top,#b88700,#ffd54d)";
        }

        if (pos === cycleStart) continue;

        while (item === values[pos]) pos++;

        // First write
        if (pos !== cycleStart) {

            bars[pos].style.background = "#ff9800";
            bars[cycleStart].style.background = "#ff9800";

            [item, values[pos]] = [values[pos], item];
            bars[pos].style.height = values[pos] + "px";

            await sleep(speed);

            bars[pos].style.background =
                "linear-gradient(to top,#b88700,#ffd54d)";
            bars[cycleStart].style.background =
                "linear-gradient(to top,#b88700,#ffd54d)";
        }

        // Rotate the cycle
        while (pos !== cycleStart) {

            pos = cycleStart;

            for (let i = cycleStart + 1; i < n; i++) {

                bars[i].style.background = "#9c27b0";
                await sleep(speed);

                if (values[i] < item) pos++;

                bars[i].style.background =
                    "linear-gradient(to top,#b88700,#ffd54d)";
            }

            while (item === values[pos]) pos++;

            bars[pos].style.background = "#ff9800";

            [item, values[pos]] = [values[pos], item];
            bars[pos].style.height = values[pos] + "px";

            await sleep(speed);

            bars[pos].style.background =
                "linear-gradient(to top,#b88700,#ffd54d)";
        }
    }

    for (let i = 0; i < n; i++) {
        bars[i].style.background = "#39d353";
        await sleep(5);
    }

    sorting = false;
}
randomize();

</script>

</body>
</html>

About this Component

Cycle Sort is a comparison-based sorting algorithm designed to minimize the number of writes to memory. Instead of repeatedly swapping adjacent elements, it determines the final position of each element and places it directly where it belongs. This makes Cycle Sort one of the algorithms with the minimum possible number of writes, making it useful in situations where memory writes are expensive. This interactive visualization lets you observe how each cycle is formed, watch elements jump directly to their final positions, randomize the input array, and control the animation speed to better understand the algorithm's unique behavior. Cycle Sort has a best-case time complexity of O(n²), and its average and worst-case time complexity is also O(n²). Although it performs many comparisons, it minimizes writes to just O(n). It is an in-place sorting algorithm requiring only O(1) additional memory, but it is not stable because equal elements may change their relative order.
